Product Description:
- Product Name: Metal Tower Packing
- Diameter: 25~90mm
- Materials: CS, SS, Copper, Titanium
- Port of Loading: Xingang Port
- Corrosion Resistance: Excellent Corrosion Resistance
- Available Types:
- Cascade Miniring Packing
- Rasching Ring Packing
- Pall Ring Packing
Metal Tower Packing Pall ring is a new type of random packing improved on Rasiichig ring.
Compared with the later, pall ring has improved the liquid
distribution of packing layer greatly, with open windows on ring
sidewall. Therefore it has productivity, low resistance, operating
flexible and higher efficiency. Hualai Pall ring is widely applied
to industry. It is still one of major annular random packing that
has been adopted. It is especially suitable for rectification
towers under vacuum to treat thermosensitive, decomposable,
polymerizable or cokable systems, so it is widely used in packing
towers in petrochemical industry, chemical fertilizer industry and
environmental protection, etc.
Features:
1.Easily wettable
2.High resistance to fouling 3.High temperature endurable 4.High
temperature applications 5.HIGH MECHANICAL STRENGTH
6.High capacity with low pressure drop
7.Mechanically robust, lesser probability of breakage
8.Good liquid/gas distribution and high mass transfer efficiency.
Technical Parameters:
| Product Name | Metal Tower Packing |
|---|
| Production Period | 40HQ/15 Days |
|---|
| Void Fraction | High Void Fraction |
|---|
| Corrosion Resistance | Excellent Corrosion Resistance |
|---|
| Key Words | Random Packing |
|---|
| Materials | CS, SS, Copper, Titanium |
|---|
| Port | Xingang |
|---|
| Diameter | 25~90mm |
|---|
| Surface Area | High Surface Area |
|---|
| Feature | High Capacity, Low Pressure Drop |
|---|
| Model | Size D*H*δ/mm | No. Per Volume n/m3 | Specific Area m2/m3 | Void Volume % | Drying Packing Factor m-1 |
| Dg16 | 16X16X0.4 | 185000 | 239 | 0.928 | 299 |
| Dg25 | 25X25X0.6 | 51900 | 219 | 0.934 | 269 |
| Dg38 | 38X38X0.8 | 13800 | 129 | 0.945 | 153 |
| Dg50 | 50X50X1.0 | 6500 | 112.3 | 0.949 | 131 |
| Dg76 | 76X76X1.2 | 1830 | 71 | 0.96 | 80 |
Applications:
Metal Pall Ring for Vacuum Distillation and Its Applications in
Heat Transfer
Metal Pall Ring is widely used in the chemical industry for Vacuum
Distillation. It is a type of industrial packing that is designed
to improve the efficiency of the distillation process. Pall Rings
are made of metal and have a unique shape that provides a large
surface area for interaction and heat transfer, making them ideal
for vacuum distillation.
The Metal Pall Ring is also used for heat transfer through multiple
applications such as:
- Wet scrubbers for gas absorption
- Cooling towers for heat transfer
- Mist eliminators for liquid particle removal
- Gas absorption columns
- Gas strippers
- Air washers
When used in wet scrubbers, Metal Pall Rings are effective in
removing harmful gases from flue gases by creating a surface for
absorption and transfer. In cooling towers, Metal Pall Rings are
used to increase the cooling capacity, and in gas absorption
columns, they are used to improve the efficiency of absorption by
increasing the interaction between the gas and the liquid.
Mist eliminators, also known as demisters, utilize Metal Pall Rings
to remove liquid particles from gas streams. They are effective in
removing small water droplets and oil from gas pipelines in
refineries, petrochemical plants, and other industrial operations.
Overall, the Metal Pall Ring is a versatile and efficient
industrial packing that is widely used in various applications in
the chemical industry.
