    Euro Style Free Standing Wrought Iron Fence Panels , Metal Palisade Fencing

    Ask Lasest Price
    Brand Name : YUANGHAI
    Model Number : YH-PF001
    Certification : ISO9001
    Price : $5.5-13.6/㎡
    • Product Details
    • Company Profile

    Euro Style Free Standing Wrought Iron Fence Panels , Metal Palisade Fencing

    Wrought Iron Fence Panel Hot Sale/ Euro Style Free Standing Metal Palisade Fence


    Wrought iron fence / steel fence description:


    Fence Panel Height: 1m-5m
    Fence Width:2m-3m
    W Pale Height: 1.0m-5.0m
    W Pale Width: 62mm, 72mm
    W Thickness: 1.5mm-4.0mm
    Top Point: Three Triple Point, Single Point,Round Point ETC.
    Material: Hot and Cold Steel Roll Belt
    Finished: Electric Galvanized, Hot Dipped Galvanized, Polyester Painting.
    Polyester Painting Color: Any RAL Series Color ( Normal RAL6005-Dark Green,RAL9005-Black)
    Angle Rail: 50mmX50mmXThickness:4mm-6mmXWidth:2.0m-2.75m
    Post: I Beam Post: 100mmX55mmXHeight:1.5m-6m,150mmX75mmXHeight:3m-6m
    Square Post:70mmX70mmX3mm,80mmX80mmX3mm
    Material: I Beam or Square Steel Pipe
    Finished: Electric Galvanized,Hot Dipped Galvanized, Polyester Painting
    Hot Dipped Galvanized: 600gram/Square meter(85micron),meet ISO EN 1461
    Polyester Painting Color: Any RAL Series Color ( Normal RAL6005-Dark Green,RAL9005-Black)
    Fish Plate: On request Or Welded onto Post
    Single Arm Or Double Arm: On Request
    Tension Wire Or Barbed Wire: On Request
    Concertina Razor Wire: On Request
    Tension Wire: On Request
    Tie Wire: On Request
    Bolts & Nuts: According to Need M8X30mm and M12X30mm,


    Materials:Q235Color:Black And Grey Or Other
    Dimensions:1800mm X 2400mm ,2100mm X 2400mm Or CustomizedSalt Spray Testing:Pass
    Treatment:Powder Coated ,Hot Dipped GalvanizedTechnical:Punch Pipes And Welding Etc
    Nick Name:Steel Fence ,Steel Tubular Fence ,Steel Spear Fence,Garrison Fence,ornamental Steel FenceUpright Pipes:25mm X 25mm X 1.20mm
    Rails:40mm X 40mm X 1.60mmPost:65mm X 65mm X 2.00mm X 3000mm
    Popular:Powder Coated Stain BlackApllication:Garden Fence, Farm Fence, Residential Fence, Highway Fence, Railway Fence, Balcony Fence, Airport Fence, Stadium Fence, Municipal Fence, Bridge Fence, Stair Fence, Air-Condition Fence

    Rails
    Rails are available in four sizes, 40 x 40, 45 x 45, 50 x 50 and 65 x 50. The size of the rail is dependant on the height of fence and level of security required.

    General Industrial Security
    ‘W’ profile 2.0mm 2.5mm 3.0mm
    ‘D’ profile

    Gates
    Gates are also available in the form of singular pedestrian gates OR double vehicle gates all as per the above spec. These gates are manufactured to look in keep as the rest of the palisade fencing system and are very reasonable as well as highly durable. All gates again are available in a RAL colour as specified.
