    Green Welded Metal Triangle Fence Panel PVC Coated With Triangle Bends

    Triangle Bending PVC Coated Welded Wire Mesh Fence

    Product Description:

    Wire Mesh Fence is a kind of ety fence for roadside, Industry zone, Villa, Highway, Railway and other public place.The fence panel with curved can make more stable and stronger, Convenient installation for square post with plastic or metal clamps.

    Product Type: Triangle bending wire mesh fence

    Material: Hot dipped galvanized wire / Electro galvanized wire

    Mesh Size: 50x200mm

    Wire Diameter: 3.0-6.0mm


    Main Features of wire mesh fence:


    1> Simple structure ,easy in installation.

    2> PVC coated, smooth and bright, looks beautiful.

    3> Perfect assembly, and with the top barbed made it very e, anti-climb.

    4> Galvanized and PVC coated, it has long services time.

    5> Fence panel with curves more stable and stronger


    Specification of wire mesh fence:


    Wire Dia. mm
    Mesh Size mm
    Length mm
    Height mm
    Fold No.
    Post Size mm
    Common Colour

    4.0

    4.5

    5.0

    5.5

    50x200

    55x200

    50x100

    75x150

    2000

    2200

    2500

    3000

    1030
    2

    Peach Post

    50x70x1.2

    70x100x1.2

    CM Post

    50x65x1.2

    65x95x1.2

    Square Post

    50x50x1.5/2.0

    60x60x1.5/2.0

    80x80x1.5/2.0

    Round Post

    48x1.5/2.0

    60x1.5/2.0

    Green-RAL6005

    Black-RAL9005

    White-RAL 9010

    Grey-RAL7030

    Red-RAL3020

    Yellow-RAL1023

    Blue-RAL5017


    1230
    2
    1530
    3
    1830
    3
    2030
    4
    2230
    4
    2430
    4

    Surface Treatment:

    Powder spray coated (powder thickness 0.1mm); PE dipped coating (powder thickness 0.8-1.2mm);

    Electro galvanized (zinc coating: 10-60g/m²); Hot dipped galvanized (zinc coating: 40-500g/m²).

    All size and dimensions are normal, bold font is the most popular size.

    Technical Date of wire mesh fence:


    1. The Wire Mesh Fence Materialis hot dipped galvanized wire

    2. Finish: PVC coated by immersion, PVC coated thickness: 1mm

    3. Each Folds or Curves have 3 or 4 horizontal wires

    4. Opening: 50x200mm

    5. Panel length: Up to 3 meters
