Description of 358 Security Fencing

• Mesh pattern: 76.2 mm (3") × 12.7 mm (0.5") resistance welded well at each intersection.
• Wire diameter: 4 mm horizontal wire and vertical Wire.
• Weld strength: range 540–690 N/m2.
• Surface treatment: 358 mesh fence panels made from galfan wire, then PVC powder coating (Min. 100 micron), or PVC powder painting. It provides additional protection and increases the potential life span.
• Colors: Green RAL 6005, or Black RAL 9005.
• Installation: Overlapped 75 mm minimum at each post (See pictures 358M-05 and 358M-06) for securing with slotted clamp bars and M8 diameter bolts.

The mesh size of horizontal wire 358 security fence is 76.2*12.7mm(center to center), the distance of horizontal wire is 12.7mm, and the distance of vertical wire is 76.2mm, it is very popular in US Market and Malaysia Market. Horizontal wire 358 Security Fence has good anti-corrosion performance, anti-aging, beautiful appearance and easy installation.

Anti-climbing - Due to the high-density mesh of the 358 guardrail, it is impossible to grasp the hands and feet, which plays a very good protection against climbing.

Anti-shear - the wire diameter is large, the mesh is dense, making the wire cut useless.

Beautiful appearance - the mesh surface is flat, two-dimensional three-dimensional, and the perspective is higher.

Horizontal wire 358 Security Fence Uses: Fence, decoration, protection and other facilities in industries such as industry, agriculture, municipalities, transportation, etc. It also used in road green belt protection nets.

Specifications of 358 Security Fencing

Features of 358 Security Fencing

• Good viewing visibility, it is a type of high security clear view fencing.
• Welded well at each intersection.
• Intrusion resistant, with extremely strong double vertical wire design.
• Small mesh aperture, anti-cut, anti-climb, finger-resistant and toe-resistant.
• Corrosion resistant with zinc aluminum alloy and PVC powder coating.
• Surface finish after welding, every weld-point are protected well.
• High strength with fully integrated with posts and anti-tamper fixings.
• Fence security toppings are optional.
• Easy for installation and free maintenance.
• 5 year warranty.

Surface treatment of 358 Security Fencing

1> Electric Galvanized Then PVC Coated(powder thickness 0.1mm)
2>Electric Galvanized Then Powder Coated(powder thickness 0.8-1.2mm)
3>Hot Dipped Galvanized Then PVC Coated(powder thickness 0.1mm)
4>Hot Dipped Galvanized Then Powder Coated(powder thickness 0.8-1.2mm)
5>Hot Dipped Galvanized After Welded(zinc coating: 40-500g/m²)
