Brand Name : | YUANHAI |
Model Number : | YH-G01 |
Certification : | ISO9001 |
Price : | USD0.6-1.3/Square Meter |
Supply Ability : | 5000m2 per month |
Galvanized Gabion Box For Retaining Wall Military Sand Wall
Gabion Box Description
Gabion box can be used for making slope, rock,slope
vegetation,rail-way or highway guardrail mesh stable. Also it can
be made
into basket, mesh mat for protecting dam which easily ruined by
flood and lead to property losses. Therefore, application of
gabion basket is the best solution of solving the problem that give
dams lasting protection.
Gabion Box Advantages
corrosion prevention ,eletrostatic prevention ,age resistance ,corrosion-resistance ,compressive resistance ,sheaving resistance and improving the protective function in the highly polluted environment .This kind of mesh mainly used in river , sea and highly polluted area .
Gabion Basket Specification
Aperture (mm) | Mesh wire (mm) | Selevage wire (mm) | Lacing wire(mm) | Max width (m) |
60x80 | 2.0-3.0mm | 3.0-4.0mm | 2.2mm | 4m |
80x100 | 2.0-3.0mm | 3.0-4.0mm | 2.2mm | 4m |
80x120 | 2.0-3.0mm | 3.0-4.0mm | 2.2mm | 4m |
100x120 | 2.0-3.0mm | 3.0-4.0mm | 2.2mm | 4m |
100x150 | 2.0-3.0mm | 3.0-4.0mm | 2.2mm | 4m |
120x150 | 2.0-3.0mm | 3.0-4.0mm | 2.2mm | 4m |
Length(m) | Width(m) | Heigh(m) | Diaphragm | Volum | Tolerance |
2.0 | 1.0 | 0.3 | 1 | 0.6 | Length:+/-3% Width:+/-5% Heigh:+/-5% |
3.0 | 1.0 | 0.3 | 2 | 0.9 | |
4.0 | 1.0 | 0.3 | 3 | 1.2 | |
2.0 | 1.0 | 0.5 | 1 | 1.0 | |
3.0 | 1.0 | 0.5 | 2 | 1.5 | |
4.0 | 1.0 | 0.5 | 3 | 2.0 | |
1.0 | 1.0 | 1.0 | 0 | 1.0 | |
1.5 | 1.0 | 1.0 | 0 | 1.5 | |
2.0 | 1.0 | 1.0 | 1 | 2.0 | |
3.0 | 1.0 | 1.0 | 2 | 3.0 | |
4.0 | 1.0 | 1.0 | 3 | 4.0 |
Gabion Basket Application
![]() |
